Name: Tritan 5206ZZ/C3 PRX Double Row Angular Contact Ball Bearing, 30MM Bore, Double Shielded
Brand: Tritan
SKU: MXT798672
Price: 15.78 USD
Availability: OutOfStock

Product Details
Shipping & Returns
Product Specifications

Manufacturer Part Number: 5206ZZ/C3 PRX

ISO CLEARANCE CLASSES

Group 1: (C1) Smaller than C2
Group 2: (C2) Smaller than Normal
Group N: (CN) Normal
Group 3: (C3) Greater than Normal
Group 4: (C4) Greater than C3
Group 5: (C5) Greater than C5

PRODUCT HIGHLIGHTS

Used in instances of heavy radal loads
Combined radial and thrust loads in (2) directional loads
Correspond in design to (2) single row angular contact ball bearings
Take up much less axial space
Provide stiff bearing arrangements
Able to accomdate tilting moments
High-speed capability
Slightly wider than single row bearings of the same bore and outside diameter
Higher load carrying capacity then single row ball bearings
Often used as fixed-end bearings
Can sustain axial loads in both directions

APPLICATIONS

Pumps and Compressors
Automotive Drives
Gearboxes
Wind Turbines
Printing Machines
Agricultural Machinery
Conveying Equipment
Electric Motors
CNC Machinery
Trucks
Mining Equipment
Robotics
Dental Equipment

Tritan 5206ZZ/C3 PRX Double row angular contact ball bearings offered by Maxtran are supplied with rubber seals (2RS), metal shields (ZZ) or Open with No seals. These high capacity 25° Contact Angle deep groove ball bearings correspond to a pair of single row angular contact ball bearings in a back-to-back arrangement, while requiring less axial space. Depending on the sealing requirements 5206 Series Double Row Ball Bearings can operate at high speeds and are more suitable than deep groove ball bearings for supporting large axial forces in both directions. Maxtran is a proud distributor of Tritan high-quality industrial-grade bearings and power transmission components. Tritan manufactures Double Row Angular Contact Ball Bearing with bores ranging from 26MM to 240MM to be used in Pumps and Compressors, Automotive Drives, Gearboxes, Wind Turbines and Printing Machines. The 5206 Series Double Row Ball Bearings require less axial space than equivalent pair of single row angular contact ball bearings and are ideal where a stiff bearing arrangement is required. Our 5206ZZ/C3 PRX Deep Groove Ball Bearings have (2) Metal Seals that protect a Fiberglass Nylon Cage. The bearing has a 30MM shaft bore, an Outside Circumference of 62MM and measures 23. 8MM overall width.
