SKF Part Number: W 30
PRODUCT HIGHLIGHTS
PRODUCT HIGHLIGHTS
- Imperial (Inch) lockwashers that is coupled with N00 and AN00 series locknuts
- W00 through W40 sizes have a 45 degree tang angle
- W44 and above have a 25 degree angle
- Engage a keyway in a shaft or adapter sleeve slot
- Locks the accompanying locknut in position by bending one of the washer tabs into the nuts outside diameter slots
- Specific sizes to accommodate metric applications
- Can be mounted directly to the shaft or on an adapter sleeve
- Manufactured from AISI grade 1020 series steel
MAXTRAN® offers a 30-Day, 100% Quality Guarantee Against Material and Manufacturing Defects Only, No Exceptions. All Claims must be made within 72-Hours of receiving your parts. MAXTRAN® is not responsible for Shipping Carrier damage or lost shipments. It is the customers responsibility to file a claim with the shipping carrier. No additIonal or implied warranties for this product are offered by MAXTRAN®. An RGA is required for all returns. We do not offer refunds without a replacement order of equal or greater value from the original order. If products are out-of-stock when a replacement is needed a store credit will be issued. Returns are only allowed for manufacturing defects and product damage. A 30% Restock Fee will be charged for all approved returns unless the product is dispositioned to be defective by our Quality Manager . All Shipping is non-refundable and any return shipping to our warehouse is the customers responsibility.
- Manufacturer:
- SKF
- Inside Diameter:
- 5.983 Inch
- Series:
- W
- Type:
- Lockwashers
